Fiat 500L Workshop Manuals and Repair Manuals

Every Manual available online - found by our community and shared for FREE. Enjoy!

Fiat 500L

The Fiat 500L is a five-door mini MPV based on the design of Fiat 500. It was codenamed Fiat L0 (or Ellezero) during development and was initially scheduled to be launched in 2011, but was delayed until the 2012 Geneva Motor Show, and later in 2012 LA Auto Show. The 500L went on sale internationally from the end of 2012, with the US and UK by spring 2013. Early models included a choice of two petrol and one diesel engines: a 1.4-litre 100 PS (74 kW; 99 hp) four-cylinder and a TwinAir with 105 PS (77 kW; 104 hp) featuring six-speed gearboxes; and a 95 PS (70 kW; 94 hp) 1.3-litre turbo-diesel with a five-speed gearbox. A 1.6-litre diesel was launched later. Altogether, the 500L is going to be for sale in over 100 countries.

Fiat 500L FAQ's

How do I check the brake fluid level in my Fiat 500L?

To check the brake fluid level in your Fiat 500L, locate the brake fluid reservoir under the hood. The fluid level should be between the "Min" and "Max" lines on the reservoir. Make sure to use the recommended brake fluid to maintain proper braking performance.

How do I check the power steering fluid level in my Fiat 500L?

To check the power steering fluid level in your Fiat 500L, locate the power steering fluid reservoir under the hood. The fluid level should be between the "Min" and "Max" lines on the reservoir. Make sure to use the recommended power steering fluid to maintain proper steering performance.

How do I check the transmission fluid level in my Fiat 500L?

To check the transmission fluid level in your Fiat 500L, start the engine and let it idle for a few minutes. Then, check the transmission fluid level using the dipstick located near the transmission. The fluid should be at the "Full" mark on the dipstick.

How do I replace the brake pads on my Fiat 500L?

To replace the brake pads on your Fiat 500L, first remove the wheel and caliper. Then, remove the old brake pads and install the new ones. Make sure to follow proper safety procedures and use the recommended tools to ensure a successful brake pad replacement.

How do I replace the cabin air filter on my Fiat 500L?

To replace the cabin air filter on your Fiat 500L, first locate the filter housing under the dashboard. Then, remove the old filter and install the new one. Regular cabin air filter replacement helps to ensure proper air flow and ventilation inside your vehicle.

How do I replace the serpentine belt on my Fiat 500L?

To replace the serpentine belt on your Fiat 500L, first locate the belt routing diagram under the hood. Then, release the tension on the belt using a serpentine belt tool. Finally, remove the old belt and install the new one. Make sure to follow proper safety procedures and use the recommended tools to ensure a successful serpentine belt replacement.

How do I replace the windshield wiper blades on my Fiat 500L?

To replace the windshield wiper blades on your Fiat 500L, first lift the wiper arm away from the windshield. Then, remove the old wiper blade and install the new one. Make sure to follow the recommended wiper blade replacement schedule to maintain proper visibility while driving.

How often should I change the oil in my Fiat 500L?

The recommended oil change interval for Fiat 500L is every 10,000 miles or once a year, whichever comes first. Regular oil changes are important to maintain the health of your engine and prevent premature wear and tear. Make sure to follow the recommended oil change schedule to prolong the life of your engine.

How often should I replace the air filter in my Fiat 500L?

The recommended air filter replacement interval for Fiat 500L is every 30,000 miles or every 3 years, whichever comes first. Regular air filter replacement helps to ensure proper engine function and performance. Make sure to follow the recommended air filter replacement schedule to maintain the health of your engine.

How often should I rotate my tires on my Fiat 500L?

The recommended tire rotation interval for Fiat 500L is every 6,000 miles. Regular tire rotation helps to ensure even wear and prolong the life of your tires. Make sure to follow the recommended tire rotation schedule to maintain the safety and performance of your vehicle.

What is the recommended battery replacement interval for Fiat 500L?

The recommended battery replacement interval for Fiat 500L is every 3-5 years. Regular battery replacement helps to ensure proper starting and charging of your vehicle. Make sure to follow the recommended battery replacement schedule to maintain the health of your vehicle's electrical system.

What is the recommended spark plug replacement interval for Fiat 500L?

The recommended spark plug replacement interval for Fiat 500L is every 100,000 miles. Regular spark plug replacement helps to ensure proper engine function and performance. Make sure to follow the recommended spark plug replacement schedule to maintain the health of your engine.

What is the recommended tire pressure for Fiat 500L?

The recommended tire pressure for Fiat 500L is 33 psi for the front tires and 35 psi for the rear tires. Proper tire pressure is important to ensure safe and efficient driving. Make sure to check your tire pressure regularly and adjust it as needed.

What type of coolant should I use for my Fiat 500L?

The recommended coolant for Fiat 500L is a 50/50 mixture of ethylene glycol antifreeze and water. This type of coolant provides excellent engine protection and prevents freezing and overheating. Make sure to use the recommended coolant to maintain the health of your engine.

What type of engine oil should I use for my Fiat 500L?

The recommended engine oil for Fiat 500L is synthetic SAE 5W-40 oil. This type of oil is designed to provide excellent engine protection and performance. It also allows for improved fuel economy and reduced emissions.

Fiat 500L Manuals Index

Fiat 500L Workshop Manual

Fiat 500L Owners Manual

Fiat 500L Misc Document
